EN
D
OpERaTION
Set up the laser:
1. Set up the laser on the floor direct
2. Set up the laser onto the multi-functional mount and fix
it to a tripod
3. Fix the magnets of the mount onto a magnetic surface
(steel plate)
4. Set up the laser in a hanging position by means of the
hole of the mount
5. Connect the laser to a column by means of the fixing strap
POWER ON
Power on the laser by turning the ON/OFF lever in position ON. The instrument is now ready for use.
An audible and optical alarm (blinking lines) indicates if the instrument was set up outside of the com-
pensator range. Set up the instrument on a more even surface.
To power off the instrument turn the ON/OFF lever back to the OFF position. The instrument is now
powered off.
NOTE:
During transport the ON/OFF lever (compensator lock) must be set to OFF . Disregard may lead to
damages of the compensator.
14
