a
b c
d
41
41
24
12
20
Functions of the display:
Green Light (A)
Green Light (B)
Red Light (C)
Red Light (C)
Red Light (D)
Red Light (D)
On hard floors the adjustment wheel (41),
moves upwards into the machine so that
the brush becomes flush with the floor.
Therefore, the Kärcher "SENSOR" can
also be used to vacuum hard floors.
On carpeted floors the adjustment wheel
(41) moves downwards out of the machine
so that the brush rises. The adjustment
wheel (41) rises and lowers to adjust the
brush to the optimal setting. This combines
effective, gentle brushing with a smooth
easy action.
When the machine is switched on in the
upright position the brush automatically
rises from the carpet. To release the
machine from the upright position, press
12
down the foot pedal (18). The brush will
automatically lower. The handle can be
lowered to an intermediate stop position in
order to lift up the brush head. To lower the
handle to a horizontal position, the foot
pedal must be pressed a second time. The
16 17
stop position can be closed off by a slider
on the swivel neck (19) so that the handle
will go from vertical to horizontal in one
movement.
To vacuum in corners etc.,
take hold of the telescopic handle grip, lift.it
away from the machine and stretch out the
hose. After use insert the telescopic attach-
ment tube into the back of the machine.
Raise the handle of the machine and the
hose will automatically retract. To use the.
hose without the tube as shown in the right
hand picture, the hose will pull out of the
tube while the tube is fitted to the machine.
Alternatively, press the release catch (27)
on picture 2.
Never run over the cable with the brush/
suction head.
Always carry the machine over steps
and sills.
Sensor XP18 230-240V
Fonctions du panneau de contrles:
Brush Lowers
Brush Raises
Flashing and Motor Off
- Brush Jammed -
Clear
Flashing and Motor On
(when machine is
upright position) - Take
Care: Brush in contact
with carpet
Continuous - Change
paper bag or clear
blockage
Flashing - Motor
switched off due to full
paper bag or blockage
Sur les sols durs la tete de brossage s'ajuste
automatiquemet par la roue (41) commandee par
son moteur. Dans ce cas, le Kärcher SENSOR
devient un veritable aspirateur pour sols durs.
Sur les moquettes et quelque soit leur epaisseur,
latete s'ajuste automatiquement de facon a se
trouver toujours dans la meilleure position
permettant un brossage et une aspiration
optimum sana abimer les fibres
Quand l'aspirateur se trouve dans sa position
haute, la brosse se souleve automatiquement du
tapis. La lampe verte (b) s'allume. Pour baisser le
manche de la machine, appuyer sur la pedale
(18), la brosse va se baisser automatiquement. Le
manche peut se bloquer dans une position inter-
mediaire afin de pouvoir soulever la tete de
brossage. Pour baisser le manche jusqu'au sol, la
pedale doit etre pressee une seconde fois. Cette
position de stop intermediaire peut etre eliminee
grace a la glissiere qui se trouve sur la rotule
d'articulation (19) ainsi le manche pourra
descendre completement en un seul mouvement.
Pour aspirer dans les coins, etc., saisissez la
poignée télescopique, soulevez-la de la machine
et étirez le tuyau. Après utilisation, insérez le tube
de fixation télescopique à l'arrière de la machine.
Soulevez la poignée de la machine et le tuyau se
rétractera automatiquement. Afin d'utiliser le
tuyau sans le tube comme indiqué sur la photo de
droite, le tuyau sera retiré du tube pendant que le
tube est fixé à la machine. Vous pouvez
également appuyer sur le bouton de déverrouil-
lage (27) comme illustré sur la photo n°2.
Ne pas passer sur le cable avec la tete d'aspi-
ration.
Toujours porter la machine.
Operations
Voyant vert (a)
Descente de la brosse
Voyant vert (b)
Montee de la brosse
Voyant rouge
En continu-changement
(c)
du rouleau-brosse
Clignotant avec moteur
Voyant rouge
eteint brosse bloquee-
(c)
libre
Clignotant avec monteur
en marche (Quand la
Voyant rouge
machine est en position
(c)
debout) Attention:
brosse en contact avec
la moquette.
permanent-changer le
Voyant rouge
sac papier ou flexible
(d)
bouche
Si elle clignote: Le mote-
umoteur s'est eteint car
Voyant rouge
le sac poussiere est
(d)
plein ou l'apareil est
houche.
