NOTE: This step is applicable after the neccessary
wiring is completed.
1.
Assemble canopy by rotating key slot in canopy
over shoulder screw in hanger bracket, taking care
not to pinch the wires. Tighten shoulder screw. Fully
assemble and tighten second shoulder screw that
was previously removed. (Figure 1)
To avoid possible fire or shock, make sure that the
electrical wires are completely inside the canopy
housing and not pinched between the housing and the
ceiling.
2.
Securely attach and tighten the canopy screw
cover over the shoulder screws in the hanger bracket
utilizing the key slot twist-lock feature. (Figure 2)
How to Assemble Your Ceiling Fan Blades
INSTALLATION NOTE
Do not connect fan blades until the fan is completely
installed. Installing the fan with blades assembled may
result in damage to the fan blades.
WARNING
To reduce the risk of personal injury, do not bend the
blades when installing, balancing or cleaning the fan.
Do not insert foreign objects in between the rotating
blades.
1. Position blades over the threaded posts and secure
with the 3/16˝-24 serrated head screws and flat
washers. (Figure 1)
How
to Install Your Canopy Housing
WARNING
HARDWARE USED:
3/16˝-24
SERRATED HEAD
SCREWS
FLAT WASHER
10
Ceiling Canopy
Figure 1
Canopy Screw
Cover
Figure 2
3/16˝-24 Serrated Head Screw
with Flat Washer (3 per blade)
Figure 1
x 9
x 9
