NOTE: This step is applicable after the neccessary wiring
is completed.
1.
Assemble canopy by rotating key slot in ceiling
canopy over shoulder screw in hanger bracket, taking
care not to pinch the wires. Tighten shoulder screws.
Fully assemble and tighten second shoulder screw
that was previously removed. (Figure 1)
To avoid possible fire or shock, make sure that the
electrical wires are completely inside the canopy
housing and not pinched between the housing and the
ceiling.
2. Securely attach and tighten the canopy screw cover
over the shoulder screws in the hanger bracket utilizing
the keyslot twist-lock feature. (Figure 2)
How to Assemble the Ceiling Fan Blades
INSTALLATION NOTE
Do not connect fan blades until the fan is completely
installed. Installing the fan with blades assembled may
result in damage to the fan blades.
▲WARNING
To reduce the risk of personal injury, do not bend the
blades when installing, balancing or cleaning the fan.
Do not insert foreign objects in between the rotating
blades.
1. Position blades over the threaded posts secure with
the 3/16˝-24 washer head screws and fiber washers.
(Figure1)
How to Install Your Canopy Housing
WARNING
HARDWARE USED:
3/16˝-24
WASHER HEAD
SCREWS
FIBER WASHER
10
Ceiling Canopy
Figure 1
Canopy Screw
Cover
Figure 2
3/16˝-24 Washer Head Screw
with Fiber Washer (3 per blade)
Figure 1
x 9
x 9
