Rimage Everest™ III and 600 User Guide
Control Panel
The control panel is located on the front of the printer. It includes an operator button and four indicator lights.
(One light is on the operator button.) The control panel allows you to monitor and control the Everest printer.
The table below identifies the name and function of all parts of the control panel.
Control Panel Indicators
Image Name
Operator button
Error indicator light (on
the operator button)
Disc Present indicator
light
Active indicator light
Power indicator light
12
All manuals and user guides at all-guides.com
Function
The Operator button is used to complete the following tasks:
•
Open the printer tray
•
Close the printer tray
•
Reset after an error
•
Put the printer into sleep mode
Tip: To put the printer into sleep mode, press and hold the
Operator button for 10 seconds. To resume normal operation,
press the Operator button again.
The Error indicator light illuminates when operator action is required.
The Disc Present indicator light illuminates when a disc is placed on
the tray or when the disc is properly clamped.
The Disc Present indicator light flashes when there is a problem. The
number of flashes in each cycle indicates the type of problem.
1 flash = Side cover is open or ribbon latch 1, 2 or 3 is open
‚
2 flashes = Print ribbon problem (incorrect, missing, or depleted
‚
print ribbon)
3 flashes = Retransfer ribbon problem (missing or depleted
‚
retransfer ribbon)
4 flashes = Error upon clamping the disc on the printer tray
‚
The Active indicator light illuminates when the printer has completed
initialization.
The Active indicator light flashes when the Everest printer is receiving
data from the host.
The Power indicator light illuminates when the Everest printer is
powered on.
