Endress+Hauser HART Micropilot FMR60B Information Technique page 24

24
Antenne encapsulée, PVDF 40 mm / 1-1/2", α = 8 °
W = D × 0,14
α
W
Antenne drip-off, PTFE 50 mm (2 in), α = 6 °
W = D × 0,10
α
W
Antenne intégrée, PEEK 20 mm / 3/4", α 14 °
W = D × 0,26
α
W
Antenne intégrée, PEEK 40 mm / 1-1/2", α = 8 °
W = D × 0,14
α
W
D
5 m (16 ft)
10 m (33 ft)
15 m (49 ft)
20 m (66 ft)
22 m (72,18 ft)
D
5 m (16 ft)
10 m (33 ft)
15 m (49 ft)
20 m (66 ft)
25 m (82 ft)
30 m (98 ft)
35 m (115 ft)
40 m (131 ft)
45 m (148 ft)
50 m (164 ft)
D
5 m (16 ft)
10 m (33 ft)
D
5 m (16 ft)
10 m (33 ft)
15 m (49 ft)
20 m (66 ft)
22 m (72,18 ft)
Micropilot FMR60B HART
W
0,70 m (2,29 ft)
1,40 m (4,58 ft)
2,09 m (6,87 ft)
2,79 m (9,16 ft)
3,08 m (10,10 ft)
W
0,52 m (1,70 ft)
1,04 m (3,41 ft)
1,56 m (5,12 ft)
2,08 m (6,82 ft)
2,60 m (8,53 ft)
3,12 m (10,24 ft)
3,64 m (11,94 ft)
4,16 m (13,65 ft)
4,68 m (15,35 ft)
5,20 m (17,06 ft)
W
1,23 m (4,04 ft)
2,46 m (8,07 ft)
W
0,70 m (2,29 ft)
1,40 m (4,58 ft)
2,09 m (6,87 ft)
2,79 m (9,16 ft)
3,08 m (10,10 ft)
