DKN technology RB-4i Mode D'emploi page 53

Nr Description Specs
1 frame #9720FT
2 rear stabiliser 95.4*50.6*2.0Tx500L
3 adjusting wheel D59*M10*40L
4 front stabiliser
5 triangle cap L 95.7*57.2*51.3
6 triangle cap R 95.7*57.2*51.3
7 spring washer D15.4xD8.2x2T
8 bolt M8*1.25*50L,8.8
9 bolt M8x1.25x20L,8.8
9A bolt M8*1.25*15L,8.8
10 slide 115*69.5*675L
11 curved washer D22xD8.5x1.5T
12 screw ST4.2x1.4x20L
13 flat washer D16xD8.5x1.2T
14 knob D61*46
15L crank L 170Lx9/16"-20BC
15R crank R 170Lx9/16"-20BC
16L pedal L JD-22A 9/16"
16R pedal R JD-22A 9/16"
17 magnets holder
18 C-ring S-17(1T)
19L L chain cover L 400.3*102.9
19R R chain cover R 400.3*102.9
20 bolt M5x0.8x15L
21 belt 420, PJ6
22 waved washer D22xD17x0.3T
23 cover for wheel 93.2*64.7*62
24 belt wheel D260*19,
25 bolt M6x1.0x15L, 8.8
anti-loosen nut
26 M6x1.0x6T
27 crank axle set
28 upper cover 380.5*140
29 handlebar post
30 pulse cable L 1750L
31 screw ST4*1.41*25L
32 handlebar set
33 screw cap D26*11L
34 bolt M8*1.0*25,10.9
35 bolt M8*1.25*15L,8.8
36 fixing plate 328*18*3T
37L chain cover L 555.2*75.4
37R chain cover R 555.2*71.6
38 backrest 440*400*92
39 adaptor 9V,1.5A
40 EU plug
41 flywheel set D280*49.2, 10kg
Qty Nr Description
1 42 seat
43 anti-loosen nut
1
44 spring washer
4
45 bolt
1
46 anti-loosen nut
2
47 nylon washer
2
20 48 dip foam
6 49 anti-slip nut
20 50 nut
51 bolt
4
52 flat washer
1
53 nut
2
54 idle wheel fix
14
55 plastic sleeve
28
56 spring washer
1
1 57 seat tube lock
1 58 anti-loosen nut
59 idle wheel
1
60 computer
1
61 UK plug
1
62 dip foam
1
63 power cable
1
64 bolt
1
2 65 protective cover
1 66 hand pulse
1 67 pulse cable
68 pulse cable U
2
69 round magnet
1
70 bearing
4
71 tension cable
4
72 computer cable
1
1 73 computer cable
1 74 sensor cable
2 75 sensor base
76 screw
2
77 bolt
1
78 round wheel
2
79 space bushing
2
80 bolt
2
1 81 Bolt
1 82 plastic washer
1 83 flat washer
1 84 flat washer
85 anti-loosen nut
1
86 space ring
1
87 screw
1
Specs Qty
440*254*75 1
M8*1.25*8T 2
D1.0*55L 1
M8*52L, 15MM 1
M6*1*6T 1
D6*D19*1.5T 1
3T 1
3/8"-26UNFx6.5T 2
M6*1*6T 1
M6*60L,8.8 1
D13*D6.5*1.0T 1
M8*1.25*6T 1
156*62.2*5T 1
D3*30L 2
D2.2*D14*65L 1
328*18*5T 1
M10x1.5x10T 1
D42*D38*24 1
SM-2572-31 1
1
D30*3T*520, 2
620L 1
M5x10L 4
100*81*40.8 1
PE18 2
500L 2
600L 4
M02 1
#6003ZZ 2
D1.5*200L, 52L 1
600 L 1
700L,12pin 1
250L 1
24*22*2.5T 1
ST4*1.41*12L 2
M10*35L(8.8) 1
D70.5*23 2
D13.5*D10*9 1
M8*1.25*40L,8.8 2
M8*1.25*30L,8.8 1
D10*D24*0.4T 2
D21*D8.5*1.5T 1
D23*D17.2*1.5T 1
M8*1.25*8T 2
D22.5*D17.2*6.4T 1
ST4*1.41*12L 8
Nr Description Specs
88 seat support
89 dip foam D7.8*1T*105L
90 bracket 58*30*4T
91 sliding cover 116.4*69.7*2.5T
92 motor
93 bolt M8*1.25*100L,8.8
94 buffer 34*34*22T
95 bolt M8x1.25x30L,8.8
96 nut M8*P1.25*6T
97 bolt M5*0.8*15L,8.8
98 bottle holder
99 screw ST4.2x1.4x20L
100 backrest cover
101 bolt M6*1.0*25L
102 screw M5*0.8*15L
103 round cap 6/8"x17
104 back support
105 console fix
106 computer base 120*40*70
107 screw ST4.2x1.4x15L
108 screw M8*1.25*45L
109 bushing D8xD12.7x23
110 anti-loosen nut M8*1.25*8T
111 line plug D4*D12*13
112 fix plate L
113 fix plate R
114 wheel D25*D10*11.5
115 bolt M5*0.8*10L,
116 flat washer D15*D5.2*1.0T
117 flat washer D18*D8.5*1.2T
118 anti-loosen nut M8*1.25*8T
119 front cover D91*220L
120 rear cover D91*220L
121 screw ST4x20L
122 inner gear disc D79.3*4T
123 outer gear disc D51.4*4T
124 spring washer D10.5*D6.1*1.3T
125 screw M6*1*10L,8.8
126 flat washer D24*D13.5*2.5T
127 anti-loosen nut M10x1.5x10T
128 excentric axle D15.9*D13*219L
129 space ring D19*D13.1*4T
130 flat washer D24xD16x1.5T
131 C-ring S-16(1T)
132 round cap 6/8"x17
133 spring washer D10*D1.5*24L
Qty
1
1
1
1
1
2
4
2
2
2
1
2
1
4
4
4
1
1
1
2
1
1
1
2
2
2
12
12
12
8
8
1
1
2
2
2
6
6
1
1
1
1
2
2
1
1
53
