THANK YOU FOR PURCHASING YOUR TIMEX® WATCH.
EXTENDED WARRANTY
Available in U.S. only. Extend your warranty for an additional 4 years from date of purchase for
$5. You can pay with AMEX, Discover, Visa or MasterCard by calling 1 800-448-4639 during normal
business hours. Payment must be made within 30 days of purchase. Name, address, telephone
number, purchase date, and 5-digit model number required. You can also mail a check for $5 to:
Timex Extended Warranty, P.O. Box 1676, Dept. EF, Little Rock, AR 72203.
Please read instructions carefully to understand how to operate your Timex® watch. Your model
may not have all of the features described in this booklet.
Remove guard from crown and push in.
HOUR HAND
DAY HAND
24 HOUR HAND
Pull Crown out to position C. Turn Crown clockwise or counter-clockwise to advance to correct
day and time. Day Hand will advance 1 day at midnight for each complete 24-hour cycle. When
done, push Crown back to position A.
Quick-set Option (If your watch does not have a 24-Hour Hand*): You can also quick-set Day
Hand by pulling Crown out to middle position B and turning clockwise to correct day. When done,
push Crown back to position A.
Note correct time of day (A.M. or P.M.) to ensure date changes at Midnight rather than
Noon. (*see "24-Hour Hand", below)
Pull Crown out to middle position B and turn counterclockwise to correct date. When done, push
Crown back to position A.
For months with fewer than 31 days, reset date at month-end.
24-HOUR HAND indicates current time on 24-hour scale. When setting watch, this hand can help
determine A.M. or P.M. For example, when Hour and Minute hand indicate 10 P.M, 24-Hour hand
would indicate "22". At 10 A.M, the 24-hour hand would indicate "10".
*24-Hour feature not available on all watch styles
FOLDOVER CLASP BRACELET
Find spring bar that connects bracelet to clasp. Using a pointed tool (Fig. 1), push spring bar in and
gently twist bracelet to disengage. Determine wrist size, then insert spring bar in correct bottom
hole (Fig. 2). Push down on spring bar, align with top hole and release to lock in place (Fig. 3).
BRACELET LINK REMOVAL
Removing Links: Place bracelet upright and insert pointed tool in open-
ing of link. Push pin forcefully in direction of arrow until link is detached
(pins are designed to be difficult to remove). Repeat until desired number
of links are removed.
Reassembly: Rejoin bracelet parts. Push pin back into link in opposite
direction of arrow. Press pin down securely into bracelet until it is flush.
SOLID LINK BRACELET
Removing Links: Using a very small screwdriver, remove screws by turn-
ing counterclockwise. Repeat until desired number of links are removed.
Do not remove links adjacent to clasp.
Reassembly: Rejoin bracelet parts and insert screw in end of opening
where it was removed. Turn screw clockwise until tight and flush with
bracelet.
If your watch is water-resistant, meter marking or (
Water-Resistance Depth
30m/98ft
50m/164ft
100m/328ft
**pounds per square inch absolute
WARNING: TO MAINTAIN WATER-RESISTANCE, DO NOT PRESS ANY BUTTONS UNDER WATER.
1. Watch is water-resistant only as long as lens, push buttons and case remain intact.
2. Watch is not a diver watch and should not be used for diving.
3. Rinse watch with fresh water after exposure to salt water.
Timex strongly recommends that a retailer or jeweler replace battery. Battery type is on
watch back. If present, push/short internal reset switch after replacing battery. Battery life
estimates are based on certain assumptions regarding usage; battery life may vary depending on
actual usage.
DO NOT DISPOSE OF BATTERY IN FIRE. DO NOT RECHARGE. KEEP LOOSE BATTERIES AWAY
FROM CHILDREN.
Register your product at
www.timex.com
W-232
START WATCH
MINUTE HAND
DATE HAND
CROWN
A B C
SECOND HAND
For easiest operation, set day and time first, then set date.
SET DAY AND TIME
24-HOUR HAND*
BRACELET ADJUSTMENT
FIG. 1
WATER RESISTANCE
NA
766-095000
HOUR HAND
DAY HAND
SET DATE
FIG. 2
) is indicated.
O
p.s.i.a. ** Water Pressure Below Surface
60
86
160
BATTERY
MINUTE HAND
CROWN
A B C
SECOND HAND
FIG. 3
