o-ring location
all o-rings are nBr 70 durometer unless otherWise stated.
valve Body (x3)
020
valve Body Front
etha Body Frm
017
sl3 inline regulator piston
sl3 inline regulator Bottom (x2)
shaft4 Barrel Back (body end)
016
shaft4 Barrel Back (tip end)
015
valve joiner external (x2)
014
o-ring
valve joiner internal
012
Firing poppet rear
sl3 inline regulator adjuster external (x2)
011
Firing poppet middle
manifold Front port
010
Firing poppet Front
009
sl3 inline regulator adjuster internal
008
oops insert external
manifold rear port
007
Body plug
006
oops insert internal (nBr 90)
005
oops push rod (x2)
poppet tip
004
location
