ION PARTY ROCKER PLUS Guide D'utilisation Rapide page 5

Features
Front Panel
1. Auxiliary input: This stereo 1/8" input
can be used to connect a smartphone,
MP3 player, or other audio source.
2. Microphone
Control (1/4"):
accept 1/4" inputs such as a microphone,
guitar, or other musical instrument.
3. Power/Charge LED: Indicates various states of activity on Party Rocker Plus.
• Solid Green LED = Party Rocker Plus is powered on.
• Solid Yellow LED = Battery is charging with the power on.
• Solid Green/Blinking Yellow LED = Party Rocker Plus is powered on and the battery
is low.
• Solid Red LED = Battery is charging with the power off.
• LED OFF = Power is off, power cable is connected, and the battery is fully charged.
4. Bluetooth LED/Disconnect Button: The LED will be lit when a device is paired to Party
Rocker Plus. This LED will not be lit when Party Rocker Plus is first powered on (unless it
was previously paired with a device). Press the button to disconnect a paired Bluetooth
device.
5. All Lights On/Off: Press this button to turn all lights on or off.
6. Light Mode: There are four modes to select from for how the dome lights react to the
music:
• Beat Sync: The dome lights spin and change color to the beat of the music playing.
• Auto: The dome lights spin and change color with a predetermined pattern regardless
of the beat of the music playing.
• Single Color: The lights change one color at a time and do not move.
• Freeze: All colors remain on and unmoving until a new mode is selected.
• Off: The dome lights turn off.
7. Light Buttons: Use these buttons to turn each color in the Dome on or off–Red, Green,
Blue, White, Pink, and Orange.
8. Echo: Use this knob to add or remove an echo effect to the Microphone Inputs.
9. Master Volume Control: This adjusts the speaker's main mix volume, which includes
Microphone Inputs, Auxiliary Input, and the audio of a paired Bluetooth device.
Inputs with Volume
These mono
1
2
inputs
7
3 5
4
6
8 9
5
