20

Remote Unit Advanced Buttons

Setup menu
To enter the setup menu, press the SETUP button on the remote control
and you will see the following display:
> 1 POWER OPTION
2 DIMMER
3 FACTORY DEFAULT
4 VERSION
5 ANTENNA SELECT
6 POWER ON VOLUME
7 EXIT
POWER OPTION, There are two choices for powering up, NORMAL
and QUICK. When set to NORMAL (Default) the unit consumes less
power during standby mode but takes a longer time to resume operation.
When set to QUICK, normal operations are started immediately after
power on.
DIMMER controls the brightness of the front panel display, it can be
dimmed with seven steps. You can access this control directly with the
DIM button on the remote control.
FACTORY DEFAULT sets the RCX-1500 into the original state as when it
left the factory. Presets and network configurations will be lost, and puts
the RCX-1500 into remote code 1 (see below).
VERSION shows this unit's version.
ANTENNA SELECT choose AUTO(default), FM or DAB antenna.
POWER ON VOLUME, sets the volume level each time the unit is
powered on.
EXIT returns to previous menu.
Second Remote Code
The RCX-1500 is set from the factory to operate with remote code 1. If
you find that the RCX-1500 remote is conflicting with other Rotel products,
you can set the RCX-1500 and the remote control to remote code 2 with
the following steps:
1, While pointing the remote at the RCX-1500, press on the remote
control 'FM'
and '2' keys at the same time. Release the 'FM' key and
continue to press the '2' key for 5 seconds. The RCX-1500 will show
'Audio Custom Code 1--> 2'.
2, Repeat the above procedure and press '1' key instead of '2' to change
the unit back to Code 1.
3. The RCX-1500 remote keys, such as PLAY, STOP, PAUSE, use Rotel's
standard codes for CD players. If you find that this is conflicting with
your Rotel CD player, press 'CD' and '2' keys at the same time. Release
'CD' key and continue to press '2' key for 5 seconds. The RCX-1500
will show 'CD Custom Code 1 --> 2'.
4. Repeat step 3 above and press '1' key instead of '2' to change the
unit back to Code 1.
RCX-1500 Stereo Compact Disc Receiver
Troubleshooting
Most difficulties in audio systems are the result of incorrect connections,
or improper control settings. If you encounter problems, isolate the area
of the difficulty, check the control settings, determine the cause of the fault
and make the necessary changes. If you are unable to get sound from the
RCX-1500, refer to the suggestions for the following conditions:
Standby Indicator Is Not Lit
The Standby Indicator should be lit whenever the RCX-1500 is plugged
into the wall power outlet. If it does not light, test the power outlet with
another electrical device, such as a lamp. Be sure the power outlet being
used is not controlled by a switch that has been turned off.
Network Does Not Work
If you have trouble connecting the RCX-1500 to your wireless network,
check your network setting carefully, these steps may help to resolve the
problem.
1. Confirm that a Wi-Fi network is available. Check that other computers
can access the Internet using the same network.
2. Check that a DHCP server is available, or that you have configured a
static IP address on the unit. Please refer to Network Config section.
3. Check that your network's firewall is not blocking any outgoing
ports.
4. Do a hard power off (unplug the AC mains) and let the unit restart
the network scanning cycle.
5. Make sure the RCX-1500 can receive the WiFi signal in its location.
Use an USB extension cord to move the WiFi dongle up higher or to a
different location to maximize reception.
No Sound
1. Check the cables between the RCX-1500 output and loudspeakers,
be sure they are connected properly. Refer to Fig. 2.
2. Music played from Internet Radio stations are affected by the speed
of your internet connection. If you find that music is cutting out regularly,
contact your internet service provider.
3. Make sure the station you selected is operating at the current hour.
The station can be broadcasting from a different time zone.
4. Please insert the Wi-Fi dongle (or wired adaptor) to the ethernet port
on the rear panel even if no networks are available. After power ON,
the unit will look for available networks before allowing the user to access
FM and DAB features.
