4. Explanation of symbols

The exclamation mark in a triangle indicates a particular risk in handling, operating or controlling the product.
The arrow symbol indicates special tips and operating information.


5. Package contents

Before assembling the model, check the piece list to make sure all parts are included.
Main components:
1 Wing centre section
2 Left and right outboard wing
3 Rudder
4 Elevator
5 Motor, propeller shaft and propeller
6 Bag with small parts such as rudder horns etc.
7 Left and right fuselage half
8 Wheels
9 Wheel axle and two wing connectors
10 Motor cover
11 Canopy
12 Tail boom with heat-shrink tubing
13 Bowden cables and push rods
Wooden parts:
1 Motor holder
2 Bearing for outer wing attachment
3 Wing support
4 Wheel axle guide
5 Wing attachment plug
6 Wing connectors (6 pieces) and servo attachment
(2 pieces)
