5.2 CMC-Box (ConnectivityMultiCall-Box)

The CMC box can be found at the head end on the left under the side beam and
only needs to be used if a reset is required.
a
a Reset-button
b Network cable

5.3 Activate the battery box

Attention!
When removing the insulating foil from the battery box, please be careful as to not
sustain cutting injuries. Wearing protective gloves is recommended.
Removing the insulating foil
– Remove the red insulating foil from the battery box to clear the charging pins.
– Check whether the insulating foil is complete and intact as shown below.
– Insulating foil (red)
– In the event of damaged insulating foil, please contact the Wissner Bosserhoff customer
service (see last page).
72
c
b
c Nursecall cable
d Connection cable Powerbox
Battery box
Insulating foil (red)
d
