Technical Specifications of the Panini Vision X P
PERFORMANCE
3 versions (sw upgradable)
VX P 50: Up to 50 DPM
VX P 75: Up to 75 DPM
VX P 100+: >100 DPM
Performance declared for 6" checks. Final performance depends on applications
and PC performance USB2.0 interface
IMPROVED AUTOMATIC DOCUMENT FEEDER
2 versions (sw upgradable):
Holding up to 50 documents – SF version
Holding up to 120 documents with unlimited continuous feeding – FF version
Double feed detection ultrasonic technology*.
Auto-tuning separator roller designed to process varied thickness of documents
and to compensate wear
MAINTENANCE
Maximum accessibility to every component to minimize MTTR
Total access to scanner and track area
Firmware upgradeable via PC
DOCUMENTS SPECIFICATIONS
Height: Min: 54 mm (2.12'') – Max: 106 mm (4.17'')
Length: Min: 80 mm (3.14'') – Max 235 mm (9.25'')
Weight: Min: 60 gr/m2 (16#) – Max: 120 gr/m2 (32#)
OPERATOR MANUAL
Vision X P Technical Specifications
ADDITIONAL OPTIONS
HW: 3 Tracks Magnetic badge reader
IR (infrared) or UV (ultraviolet) front image capture for security applications
HW: External dongle for temporary and device independent upgrades
SW: OCR Recognition: OCR-A, OCR-B
SW: Barcode Recognition: Code 39, Interleaved 2/5, EAN8, EAN13, UPCA,
UPCE, Code 128
SW: 2D barcode (PDF 417, Datamatrix)
POCKETSTwo exit pockets capable of holding 100 documents each.
Flexible Sorting Options, based on MICR and/or image
Full pocket sensor .
MAGNETIC READER
E13B/CMC7/Automatic
New Panini MICR Plus® exclusive technology with OCR assist feature
Superior MICR recognition and management MICR based sorting
SOFTWARE TOOLS
Panini Vision API control running on:
Windows 2000 S.P. 3, XP, Windows Vista with USB 2.0 or USB 1.1
ICR Vision function for image snippet definition and download
Easy integration of ICR/Barcode/OCR recognition technology
Page 48
*In particular environmental circumstances and typically at very high
altitude, a special calibration could be required.
Please contact your provider for further details.
Vision X P Addendum
