6. Specifications

6.1 Technical Specifications of the Panini Vision X
PERFORMANCE
IMPROVED AUTOMATIC
DOCUMENT FEEDER
INKJET PRINTER
TOTAL COMPATIBILITY
AND SCALABILITY
POCKETS
WORKSPACE
DOCUMENT SPECIFICATION
INTERFACE
OPERATOR MANUAL
3 versions (sw upgradable)
VX 50: Up to 50 DPM
VX 75: Up to 75 DPM
VX 100+: >100 DPM
Performance declared for 6'' checks. Final performance depends on applications and PC performance
USB 2.0 interface
3 versions (sw upgradable)
- single document automatic drop - 1F version
- holding up to 50 documents - SF version
- holding up to 100 documents with unlimited continuous feeding - FF version
Double feed detection with ultrasonic technology*
Auto-tuning separator rollers designed to process varied thickness of documents and to compensate
wear
*In particular environmental circumstances and typically at very high altitude, a
special calibration could be required. Please contact your provider for further details.
2 versions (sw upgradable)
Rear Ink-jet Printer (IJ version) and No ink jet (NJ version, sw upgradable)
Printing capability: Single line, Alphanumeric characters, all MS Windows fonts
Reg CC Compliant
Printed information captured by the image
Intelligent printing, image and MICR driven
Automatic cartridge presence detection and empty cartridge alert
Total backward compatibility for software API > release 3.00.
Full version scalability (for sw options) throughout the range, via software upgrade.
A single exit pocket capable of holding up to 100 documents
Extremely compact footprint - Ideal for teller, back office and corporate installations
Height: Min: 54 mm (2.12'') - Max: 106 mm (4.17'')
Length: Min: 80 mm (3.14'') - Max 235 mm (9.25'')
Weight: Min: 60 gr/m2 (16#) - Max: 120 gr/m2 (32#)
USB2.0 port/Backward compatible with USB 1.1
RS232 Port for external device connection. (SW/FW developments on request.)
Page 39 Specifications
