3.4 USB Cable Connection
Connect the USB cable to the USB 2.0 port located on the rear
side of the scanner, and then connect the other end of the cable to
an available USB 2.0 port on the PC.
3.5 Ink-Jet Cartridge Installation (*Optional)
Remove the inner cover (see section 5.1 for details). Take a new Ink-Jet cartridge out from its package. Do
not touch the ink with your fingers or clothing: it will stain. Angle the front side of the cartridge downwards
and face the two pins with the two holes in the cradle. Gently push down the rear side of the cartridge until it
snaps in the plastic retainer.
* If the unit was purchased without the endorser option then the unit is shipped without an ink cartridge and that one is
not needed to run the device.
Plastic retainer
OPERATOR MANUAL
Ink-Jet Cartridge Panini P/N:
CA-109765
Castridge cradle
Page 18
USB cable
Operating your Panini Vision X
