6. Belt Fitting of the RsqTec "TURTLE"
Before starting the belt fitting, all belts and snap buckles are opened and laid to one side. Now the injured person
is laid on his or her back on the RsqTec TURTLE so that his or her crown is approx. 5 cm away below (caudal)
from the upper (cranial) edge of the protective tray. Then the tabularly represented step-by-step instructions for
the correct belt fitting are carried out.
Illustration
Mittelmann Sicherheitstechnik GmbH & Co. KG - Bessemerstrasse 25 - DE-42551 Velbert
Phone : +49 (0)2051 / 91219-00 – Fax : +49 (0)2051 / 91219-19 – E-mail: info@mittelmann.com
- 6 -
Description
Coming from the side, pass the long belt side of the leg
strap (red (g) and green (h)) under the respective thigh of
the person. Guide them up through the crotch and connect
them to the relevant snap buckles (the snap buckles must
audibly and tactilely snap into place). The strap is pulled
tight (not constricting) without changing the position of
the person in the process.
Lay the shoulder strap (e) over the head of the person in
the longitudinal direction, guide it over the shoulder and
connect it at the front of the chest with the side parts of
the chest strap (f). The strap is pulled tight (not
constricting).
The complete freedom of movement of the rib cage for
breathing must be strictly maintained.
