4. Product Description
The "TURTLE" rescue harness with carrying function is a combination of patient transport means and a rescue
harness and has been tested and certified in accordance with DIN EN 1497:2007 and DIN EN 1865-1:2015 Ziffer
5.4.1.
TURTLE is a rescue system, made using textile materials, for the rescue and transport of accident victims. The
textile sheath (a) encases the person from the chest to the buttocks area. Fastening is done by means of large
size Velcro strips. Two lashing belts (b) with adjustable Cobra snap buckles serve for tightening of the protective
cover around the person's body. A system of supporting longitudinal, lateral and diagonal belts inside the
stretcher carry the body weight of the person during the rescue and transport operations. The head strap (c) on
the upper part of the stretcher serves for the pulling it horizontally. Opposite to this there is a buttocks strap (d).
The shoulder straps (e) are adaptable by means of adjustable buckles that in turn are connected to the horizontal
chest strap (f) via two snap buckles. Additional supporting straps are the leg straps left (g) and right (h) that also
can be adjusted in length for each person by means of the Cobra snap buckles. The rescue and transport of a
horizontally lying person is performed via anchoring to the four suspension loops (i) that can be optionally
equipped with two round rings (two loops per ring) or with four shackles. The transport of a vertically hanging
person takes place by means of the vertical suspension loop (k). In addition, there are carrying loops with handles
(j) on the outside of the rescue harness for manual transport.
5. Designation of the Individual Parts
No.
Designation
(a)
Textile sheath (blue)
(b)
2x lashing belts (black)
(c)
1x head strap (yellow + blue belt)
(d)
1x buttocks strap (yellow + blue belt)
(e)
2x shoulder straps (blue)
(f)
1x chest strap (blue)
(g)
1x leg strap left (red belt)
(h)
1x leg strap right (green belt)
(i)
4x suspension loops (belt straps with round rings / shackles)
(j)
4x carrying loops with handles (black + blue)
(k)
1x suspension loop
Mittelmann Sicherheitstechnik GmbH & Co. KG - Bessemerstrasse 25 - DE-42551 Velbert
Phone : +49 (0)2051 / 91219-00 – Fax : +49 (0)2051 / 91219-19 – E-mail: info@mittelmann.com
- 4 -
Anchor points for these lying
positions
For horizontal pulling
For horizontal pulling
For horizontal lifting
No anchor point
For vertical lifting
