• Operating Instructions • Warning Information
S P E C I F I C A T I O N S
Capacity ...................................................................... 5 Ton
Low Height . .................................................................5-3/4"
High Height . ..............................................................22-1/2"
Chassis Length ............................................................... 56"
Front Width . ..............................................................11-1/2"
Rear Width . ...............................................................14-3/4"
Handle Length . ................................................................ 42"
Weight..................................................................... 210 Lbs
This is a LifTing Device OnLY. DO nOT MOve Or DOLLY The vehicLe WhiLe
On The Jack. iMMeDiaTeLY afTer LifTing sUPPOrT The vehicLe WiTh
aPPrOPriaTe Means.
DO nOT OverLOaD. OverLOaDing can caUse DaMage TO Or faiLUre Of
The Jack.
LifT OnLY On areas Of The vehicLe as sPecifieD bY The vehicLe
ManUfacTUrer.
cenTer LOaD On saDDLe PriOr TO LifTing. Off-cenTer LOaDs MaY caUse
DaMage TO Jack, LOss Of LOaD, PrOPerTY DaMage, PersOnaL Or faTaL
inJUrY.
This Jack is DesigneD fOr Use OnLY On harD LeveL sUrfaces caPabLe
Of sUsTaining The LOaD. Use On OTher Than harD LeveL sUrfaces can
resULT in Jack insTabiLiTY anD POssibLe LOss Of LOaD.
nO aLTeraTiOns TO The Jack shaLL be MaDe.
reaD, sTUDY anD UnDersTanD The OPeraTing ManUaL PackeD WiTh This
Jack befOre OPeraTing.
faiLUre TO heeD These Warnings MaY resULT in LOss Of LOaD, DaMage
TO Jack, anD/Or faiLUre resULTing in PrOPerTY DaMage, PersOnaL Or
faTaL inJUrY.
MSJ5
• Parts Breakdown
MSJ5
The jack must be removed from service immediately
and inspected by a manufacturer's repair facility if it
is subjected to an abnormal shock or load.
FOR YOUR SAFETY AND TO PREVENT INJURY:
®
1-1/2 TON
CAPACITY
PROFESSIONAL
RATCHETING
JACK STAND
Made to Matco
Specifications
in China

MSJ5
5 Ton
Service Jack
Use Service Jack
for lifting purposes
ONLY.
Always support
vehicle with
jack stands.
Copyright © Professional Tool Products, 2007
All rights reserved
®
®
1-1/2 TON
CAPACITY
PROFESSIONAL
RATCHETING
JACK STAND
Made to Matco
Specifications
in China
Rev. 09/04/07
