S S
YSTEM PECIFICATIONS
S8 C
OMPACT
Performance: Operating pressure range: 4 to 20 cm H
Dimensions (H x W x D): 4.6" x 6.5" x 5.7" (112 mm x 164 mm x 145 mm)
Weight: 2.9 lb (1.3 kg)
Power Supply
Input range for
2.5A < 140VA (110W) (maximum power consumption). Instantaneous peak power
consumption <340 VA.
Actual power consumption will vary, depending on factors such as the use of
accessories, height above sea level, and ambient temperature. Power consumption
values for typical treatment conditions (using a breathing machine set to 0.5 L and
15 breaths/min with 6'6" (2 m) air tubing and an
following table.
Device
S8 C
OMPACT
Power outlet for HumidAire 3i
Outlet range: 100–240V, 50/60Hz; 110V, 400Hz; 2.0A
Air Filter: Two-layered, powder-bonded, polyester non-woven fiber
Air Tubing: Flexible plastic, 6'6" (2 m)
Air Outlet: The 22 mm conical outlet complies with EN 1281-1
IEC 60601-1 Classifications: Class II (double insulation), Type CF
Noise Level: Radiated sound pressure is measured at <30dBA at 10 cm H
3'3.36" (1 m) according to ISO17510-1.
Housing Construction: Flame retardant engineering thermoplastic
Environmental Conditions
Operating Temperature: +41°F to +104°F (+5°C to +40°C)
Operating Humidity: 10%–95% non-condensing
Storage and Transport Temperature: -4°F to +140°F (-20°C to +60°C)
Storage and Transport Humidity: 10%–95% non-condensing
Operating Altitude: sea level to 8500' (2591 m)
22
S8 C with H A
OMPACT UMID
Pressure
(cm H O)
2
5
10
15
20
O
2
3i :100–240V, 50/60Hz; 110V, 400Hz;
IRE
U M mask) are given in the
LTRA IRAGE
Power Power
(VA) (W)
17 8
23 12
29 16
34 20
O and
