c. Two channel remote control transmitter
Included in the scope of delivery is a remote control
transmitter with two remote control levers, which are assigned
the two respective functions.
These functions are activated by the movements forwards /
backwards and right / left.
AA X 8 batteries are required for the
transmitter (not included)
Trim lever pitch
Pitch (Lift)
Tail (Rudder)
Trim lever tail
Transmitter crystal
Functions on the back of the transmitter:
• Charging socket
• Battery chamber
Put the charged batteries in the battery compartment of the
transmitter.
Pay attention to the correct polarity!
Telescopic antenna
Servo reverse switches
to change the reaction direction
CARSON Big CFG Helicopter 507011
GB
Trim lever nick
Nick (Elevators)
Roll (Ailerons)
Trim lever roll
ON/OFF switch
