SYSTEM LAY-OUT

❷
❺ ❶
1 - KING operator
2 - Tuned aerial
3 - Flashing lamp
4 - Key selector
5 - Photoelectric cells (external)
1 V OPEN
2 W CLOSE
3 U COMMON
Yellow/Green
❸
❹
❶ ❺ ❹
1
19

TECHNICAL FEATURES

KING is a series of linear irreversible operators, suitable for opening gates with
a leaf length of up to 5 metres (Fig.1).
The KING operators use mechanical stoppers, thus avoiding the need for
electrical limit switches.
On reaching the travel limit, the motor continues to operate for a few seconds,
until the timer of the control unit cuts in.
TECHNICAL DATA
Max. leaf length m
Max. leaf weight kg
Max. travel mm
Average opening time s.
Operating speed m/s.
Thrust force N
EEC Power supply
Motor capacity W
Power absorbed A
Capacitor µF
EEC Power supply
Motor capacity W
Power absorbed A
Capacitor µF
EEC Power supply
Motor capacity W
Power absorbed A
Capacitor µF
Normative cycles 230V n°
Normative cycles 220V n°
Normative cycles 120V n°
Daily operations suggested n°
Service
Guaranteed consecutive cycles n°
Grease
Weight of electroreducer kg
Noise db
Volume m
3
Operating Temperature °C
Protection IP
* With incorporated mechanical stop that cuts in during opening. - If the mechanical stop is
used during closing (optional), the maximum travel is reduced by 50 mm.
KING L=888
KING L L=1020
Measurements in mm
KING KING L
4 5
400 500
345* 475*
14÷27 29÷38
0,0125
1800
230V~ 50Hz
290
1,2
10
220V~ 60Hz
225
1,04
8
120V~ 60Hz
255
2,3
35
17 - 14s/2s 10 - 33s/2s
31 - 14s/2s 20 - 33s/2s
29 - 14s/2s 11 - 35s/2s
150
60%
20/14s 15/33s
Bechem - RHUS 550
10 14
<70
0,0184 0,0211
-10 ÷ +55
44
L1=815 L2=340
L1=945 L2=470
G
B
