English–1

Safety Notes

Read all safety warnings and all instruc-
tions. Failure to follow the warnings and in-
structions may result in electric shock, fire
and/or serious injury.
Save all safety warnings and instructions for future
reference.
The term "battery" is used in these instructions to mean all
original Bosch eBike rechargeable battery packs.
 Do not use the on-board computer as a handle. Lifting
the eBike up by the on-board computer can cause irrepara-
ble damage to the on-board computer.
 Make sure to not be distracted by the display of the on-
board computer. If you do not focus exclusively on the
traffic, you risk being involved in an accident. If you want to
make entries in your on-board computer other than switch-
ing the assistance level, stop and enter the appropriate
data.
 Read and observe the safety warnings and instructions
in all operating instructions of the eBike system and in
the operating instructions of your eBike.
Product Description and
Specifications
Intended Use
The Intuvia on-board computer is designed to control Bosch
eBike systems and display riding data.
In addition to the functions shown here, changes to software
relating to troubleshooting and functional enhancements may
be introduced at any time.

Product Features

The numbering of the components shown refers to the illus-
trations on the graphic pages at the beginning of the manual.
Individual illustrations in these operating instructions may dif-
fer slightly from the actual circumstances depending on the
equipment of your eBike.
1 Display-function button "i"
2 Bike lights button
3 On-board computer
4 Holder for on-board computer
5 On/Off button for on-board computer
6 "RESET" button
1 270 020 XBI | (19.4.17)
7 USB port
8 Protective cap of USB port
9 Operating unit
10 Display-function button "i" on the operating unit
11 Decrease assistance level/scroll down button "–"
12 Increase assistance level/scroll up button "+"
13 Push-assistance button "WALK"
14 Lock latch for on-board computer
15 Locking screw for on-board computer
USB charging cable (Micro A – Micro B)*
* not illustrated; available as accessory
Display elements of on-board computer
a Drive unit assistance indicator
b Assistance-level indicator
c Light indicator
d Text indication
e Value indication
f Speed indication
g Shift recommendation: higher gear
h Shift recommendation: lower gear
i Battery charge-control indicator

Technical Data

On-board computer
Article number
Max. charging current,
USB connection
Charging voltage,
USB connection
1)
USB charging cable
Operating temperature
Storage temperature
Charging temperature
Internal lithium-ion battery
2)
Protection type
Weight, approx.
1) Not included in standard scope of delivery
2) When USB cover is closed
Bosch eBike system uses FreeRTOS (see www.freertos.org)
36
Intuvia
1 270 020 906/909
mA 500
V
1 270 016 360
°C –5...+40
°C –10...+50
°C 0...+40
V 3.7
mAh 230
IP 54 (dust and splash
water protected)
kg 0.15
