RDN 575BT
1 2 3 16 19 7 5 6 8 9
21
1 2 3 4
15
5
16
6
17
7 18
19
8
20
9 21
10 22
11 23
12 24
25
13
14
26
1. q: power ON/OFF
2. MOD: mode select
3. 12: play/pause playback
4. MUte: mute audio output
5. BAnD: band select
(tuner)
6. Cursor buttons and
conformation button
7. 3: stop playback

Basic operations

Main Menu
Tap the 0 on screen button to show the main menu. On the home screen you can
choose the available modes (RADIO / DISC / Bluetooth / SD / USB / AUX / AV /
Bluetooth Music) or enter the CALENDAR, SWC settings or SETUP menu.
Sound control
• Volume
Turn the [VOL] button (7) to adjust the volume level.
• Audio settings
By pushing the [SEL] button (7) you will enter the audio menu and you can adjust
BASS / TREBLE / BALANCE / FADER. Push to choose and rotate to adjust.
Note:
when an EQ preset is chosen the bass and treble control are not available.
• Other Audio Settings
Settings like preset equalizer or loudness can be set by tapping the [SETUP] in
the main menu.
Day/night display mode
Tap the on-screen Sun button in the top bar to increase brightness. Tap again to
reduce brightness during night time. Tap again to black out the screen.
Setup
Enter the setup menu by tapping the [SETUP] icon on the main menu.
Tap the items you would like to set. You can adjust audio, date and time, language,
calibration, etc.
QUICKStaRtGUIDE
10 11 12 13 14 18 17 15
22 23
8. St/PrOG: stereo selection / program
tracks to be played
(disc/USB/SD)
9. AMS/rPt: intro play stations
(tuner)
repeat options
(disc/USB/SD)
10. 7/seek: previous track
(disc/USB/SD/
/ frequency seek down
BT) (tuner)
11. LOc/rMD: local selection
(tuner)
shuffle play options
(disc/USB/SD)
12. OSD: show playback Menu
(disc/USB/SD)
13. PBc: playback control
(disc/USB/SD)
14. Numeric buttons
15. tItLe: shows title
(DVD only)
16. SUB-t: subtitle select
(DVD only)
17. SetUP: shows setup menu
18. AnGLe: change angle
(DVD only - if available)
19. SLOW: slow-motion playback
(DVD only)
20. Volume up
21. ZOOM: zoom steps
(DVD only)
22. SeLect: Audio menu
23. 8/seek: next track
(disc/USB/SD/BT)
frequency seek up
(tuner)
24. Volume down
25. AUDIO: change audio output method
(DVD only)
26. GO tO: Track time search
(disc/USB/SD/BT)
1. tFt monitor:
Motorized slide-in/out 7" TFT-LCD touch
screen
2. POWer / tFt:
- Unit power
- Open/close the TFT monitor
3. MOD:
Switch between Radio/Disc/USB/SD/
AUX-in/Bluetooth/A2DP/AV-in
4. MUt:
Push: mute audio output
Hold: TFT backlight ON/OFF
5. s / nAVI
20 4
- Enter Navigation
- TFT monitor angle (4 steps)
6. w / MenU
- Enter Menu
- TFT monitor angle (4 steps)
7. VOL / audio menu:
Adjust volume (rotary)
- Adjust audio* (push to enter)
*only available when no EQ is selected
8. LcD Screen:
Displays track/station info
9. #1 / OSD:
Tuner: memory nr. 1
Disc: show on-screen info
10. #2 / rPt:
Tuner: memory nr. 2
Disc: choose repeat modes

radio operations

Band
/
Tap the on-screen [BAND] button to choose FM1, FM2, FM3, AM1 or AM2.
On each band up to 6 presets can be stored.
radio Seek Function
/
In Radio Mode, touch and hold the < or > button to adjust seek the frequency
automatically. Tap the button to adjust the radio frequency manually step-by-step.
Save preset stations
There are six numbered preset buttons on the screen (P1-P6), which can store
and recall stations for each band. Tune in to the station you want to store, touch
and hold any key from P1-P6 until you hear a beep. The station will be saved in
the designated number.
rDS
AF, TA, PTY are the RDS functions. Tap the on-screen buttons to turn these
functions ON/OFF.
Note: RDS might not be available in every country.

Bluetooth operations

/
Pairing
Activate Bluetooth on your mobile phone, and search for available devices. Select
"RDN575BT Caliber", password "0000". If successful connected the Bluetooth logo
stays ON, if not this logo keeps flashing.
Dial pad
Touch the dial pad to dial the number you would like to call. Touch the [CALL]
(green) button to send the number.
call list
Displays your phonebook and call history, if you've given permission.
A2DP
Go to the Bluetooth music mode to control playing music of your cell phone using
the on-screen controls (available if you device supports A2DP).
Incoming calls
• Answer call: push the green horn at an incoming call
• End call: push the red horn
• Reject call: push the red horn at an incoming call
Disc/USB/SD operations
Place a the Disc/USB/SD card into the unit. The unit will start playing the contents
automatically, else go the right mode.
Audio playback
To control the audio playback, use the on-screen buttons.
DVD/Movie playback
Push the [SEL] button (7) to show the playback options
Image playback
Push the [SEL] button (7) to show the playback options
Folder/file list
To show the contents of the Disc/USB/SD, tap the 0 on-screen button to go back
till the file directory is shown. The files are divided into audio, movies and pictures.
11. #3
Tuner: memory nr. 3
12. #4 / rDM:
Tuner: memory nr. 4
Disc: shuffle playback mode
13. #5 / StOP:
Tuner: memory nr. 5
Disc: stop playback
14. #6 / PAU:
Tuner: memory nr. 6
Disc: pause playback
15. USB Slot
(max. 32GB)
16. 7:
Auto search / Previous track
17. ':
Eject disc
18. AUX In socket:
Suitable for 3.5mm jack plug
19. 8:
Auto search / Next track
20. reL:
Frontpanel release button
21. GPS card Slot
(SD with navi maps only)
22. SD card Slot
(max. 32GB)
23. reSet:
Reset unit to factory settings
