7 TECHNICAL SPECIFICATIONS

7.1

TECHNICAL CHARACTERISTICS

Accuracy calculated as ± [%reading + (num. dgt) * resolution] at 23°C ± 5°C, <80%RH
Continuity of protection conductors
Range []
0.001  1.999
Test current:
Open voltage:
Measurement time:
Measurement method:
Overheating
Test current
Range [A]
0.00  19.99
7.2

REFERENCE GUIDELINES

Safety:
EMC:
RED:
EMC environment of use:
Insulation:
Pollution level:
Measurements:
Measurement category:
7.3

GENERAL CHARACTERISTICS

Power supply
Main's supply:
Power consumption:
Fuse protection:
Check that the rated operating voltage value indicated on the back label
should be consistent with the power supply voltage of the system under
test
External communication
MASTER instrument interface: optical cable C2050
Mobile devices interface:
Internal status indications:
Mechanical characteristics
Dimensions (L x W x H):
Weight (with integrated cable): approx. 1kg (32ounces)
Mechanical protection:
Resolution []
>10A AC (max test cable resistance 0.7)
4< Vo < 24V AC
10 periods (@ 50Hz), 12 periods (@60Hz)
4-wires
after at least 20 consecutive tests
Resolution [A]
IEC/EN61010-1, IEC/EN61010-2-030, IEC/EN61557-1
IEC/EN61326-1, IEC/EN61326-2-2
ETSI EN300328, ETSI EN303446-1, ETSI EN301489-17
portable, Class B, Group 1
double insulation
2
IEC/EN61439-1, IEC/EN60204-1, IEC/EN62305-3
CAT III 300V to ground and between inputs
230V/240V ±10%, 50/60Hz or 110V ±10%, 50/60Hz
max 70W (@230V, 300mA) (@110V, 600mA)
Time-Leg 250V/1A (5x20mm)
WiFi (via APP HTAnalysis)
two colors LEDs
210 x 115 x 60mm (8 x 5 x 2in)
IP40
0.001
0.01
CAUTION
EN - 11
EQUITEST
Accuracy
(1.0rdg + 2dgt)
Accuracy
(1.0rdg + 2dgt)
