4.3 STATUS DESCRIPTION OF LED INDICATORS

LED
This LED identifies the power on status of the accessory. The following
situations are possible:
POWER
 Off  accessory not powered
 Green  accessory powered with correct voltage
 Red  accessory powered with incorrect voltage
This LED identifies the connection status of the internal WiFi module. The
following situations are possible:
 Off  no WiFi connection
WiFi
 Green steady  WiFi connection active
 Green flashing  accessory waiting for WiFi connection
 Red  internal WiFi module malfunction (contact the after-sales
This LED identifies the type of measurement performed in connection with
the MASTER unit (see relevant user manual). The following situations are
possible:
STATUS
 Green  operation in Manual mode
 Orange  operation in Autotest mode
 Red  there are connection errors (contact the after-sales service)
service)
Description
