4. Connect the two black cables of the C7000 cable set to the input sockets P1 and P2
and the two red cables to the input sockets C1 and C2 (see Fig. 3)
5. Connect the alligator clips of the C7000 cable set to the ends of the object under test
(see Fig. 3)
6. Press the GO/STOP key on the MASTER instrument to activate the test in Manual
mode. The accessory provides the test current >10A AC and the measurement result
is shown on the display of the MASTER instrument (see related user manual)
7. By selecting the Automatic mode on the MASTER instrument (measurement activated
without using the GO/STOP key) check that the STATUS LED should be steady
orange and connect the alligator clips to the ends of the object under test (see Fig. 3)
to automatically activate the test
8. To save and manage the result, refer to the user manual of the MASTER instrument
