Sportplus SP-HT-1300-B-iE Instructions D'utilisation page 31

Parts number Description and information
35 Hex nut M10 x 8t
36 Hex nut M6 x 5t
37 Belt wheel
38 Flange nut M10 x 8t x 1.25P
39 Magnetic arm
40 Nylon nut M10 x 8t
41 Self-tapping screw ST4.2 x 20L
42 Flywheel
43 Washer φ10.3 x φ25 x 1.5t
44 Plate
45 Washer φ5.2 x φ18 x 1.5t
46 Tension pulley axle
47 Axle for main frame
48 Hex screw M8 x 80L
49 Screw M6 x 10L
50 C clip 17
51 C clip 15
52 Ball bearings
53 Hex screw M6 x 30t
54 Self-tapping screw ST4.2x15L
55 Curved washer
56 Spring
57 Setting set
58 Plastic washer φ6.5 x φ13 x 0.5t
59 Belt wheel 2
60 Plastic washer φ20 x φ8.5 x 2t
61 Cable gland
62 Crank L
63 Crank R
64 Bearing block
65 Housing L
66 Housing R
67 Housing cover
31
Quantity
2
1
1
2
1
1
2
1
1
2
1
1
1
1
6
6
1
1
1
2
3
1
2
1
1
2
1
1
1
2
1
1
1
