Using Phantom 4 RTK
1. Mount the Remote Controller Battery
The remote controller uses an easily removable interchangeable
Intelligent Battery for long-term operation.
Slide the battery compartment cover lock on the back of the
1
remote controller down to open the cover.
Insert the Intelligent Battery into the compartment and push it
2
to the top.
Close the cover.
3
To remove the Intelligent Battery, open the cover, press and hold the battery release button, then push the
●
battery downward.
2. Mount the Dongle and SIM Card (optional)
The Phantom 4 RTK remote controller can access the Internet via a 4G dongle with SIM card or Wi-Fi signal.
●
For connection to a Network RTK, using a 4G dongle with SIM card mounted to the remote controller is
recommended. When uploading or downloading system logs or operation data, using a Wi-Fi signal for
Internet access is recommended.
Only use a DJI approved dongle.
●
Use a SIM card that is compatible with the chosen mobile network provider and select a mobile data plan
●
according to the planned level of usage.
The dongle and SIM card are used to enable the remote controller to access to specific networks and platforms,
●
such as the DJI AG platform. Be sure to mount them correctly, or else network access will not be available.
Lift the dongle compartment cover
at the gap at its lower right corner,
then remove it.
* Test procedure: Press the remote controller power button once, then press again and hold to turn the remote
controller on. In the DJI GS RTK app tap
in the network chain are shown in green the dongle and SIM card are functioning properly.
3. Check the Battery Levels
Press once to check the battery level. Short press once, then long press and hold to turn on/off.
4
Dongle
Insert the dongle into the USB
port with the SIM card inserted
into the dongle and test. *
> and select Network Diagnostics. If the statuses of all the devices
Low High
3
Battery Release
2
Buttoon
Re-mount the cover. To secure the
cover, open the silicone protectors
on it, insert and tighten two Phillips
screws, then close the protectors.
Low High
