Phantom 4 RTK
The PHANTOM
TM
4 RTK is a smart mapping and imaging drone capable of highly accurate mapping functions.
The aircraft has a built-in DJI
accuracy. Multi-directional obstacle sensing is enabled by forward, rear, and downward vision and infrared
sensors*. The camera features a 1-inch 20-megapixel CMOS sensor housed within a high stability gimbal.
When it comes to mapping, the high-performance mechanical shutter eliminates rolling shutter distortion when
capturing images at speed. Image data can be used to generate maps for field planning when operating a
DJI AGRAS
TM
aircraft. Users can also import photos to the DJI PC GS Pro application or third-party mapping
software to composite highly accurate maps for different applications.
1. Gimbal and Camera
2. Downward Vision System
3. Micro USB Port
4. Camera/Linking Status Indicator and
Link Button
5. Camera microSD Card Slot
6. Forward Vision System
7. Infrared Sensing System
8. Front LEDs
9. Motors
* This should be used with Network RTK service, a DJI D-RTK 2 High-Precision GNSS Mobile Station (purchased
additionally) or post-processed kinematic (PPK) data (recommended when RTK signal is weak during operation).
The Vision and Infrared Sensing Systems are affected by surrounding conditions. Read the Disclaimer and Safety
Guidelines to learn more.
2
TM
Onboard D-RTK*, which provides precision data for centimeter-level positioning
13
6
12
1
10. Propellers
11. Aircraft Status Indicators
12. OCUSYNC
13. Onboard D-RTK
Antenna
14. Rear Vision System
15. Intelligent Flight Battery
16. Power Button
17. Battery Level Indicators
10
9
8
7
5
4
3
2
Antennas
TM
TM
11
17
16
15
14
