Display window
1
w
1 Status of Bluetooth device
(Device number, [P: 1 – 5]; signal strength,
[
: 0 – 3]*; battery reminder, [ : 0 – 3]*)
2 Tr (track) indicator
3 Source display / Preset number / Disc number /
Track number / Folder number / Setting and list
operation information
4
(USB) indicator
5
(iPod/iPhone) indicator
6 HD (HD Radio™ broadcast) indicator
7 Playback mode / item indicators—RND (random),
(disc),
(folder), RPT (repeat)
You can change the display and button illumination (see page 32).
Using the remote controller (RM-RK50)
Installing the lithium coin battery (CR2025)
Caution:
• Danger of explosion if battery is incorrectly replaced.
Replace only with the same or equivalent type.
• Battery shall not be exposed to excessive heat such as
sunshine, fire, or the like.
If the effectiveness of the remote controller
decreases, replace the battery.
2
3
45
6
7
89
e
8 HOLD (reception hold) indicator
9 ST (stereo) indicator
p
TAG (PSD reception) indicator
q Disc/device information indicators—
file) and
(folder)
w
(Bluetooth) indicator
e Main display
r Menu hierarchy position indicator— (top),
(middle), (bottom)
* As the number increases, the signal/battery power
becomes stronger.
For USA-California Only:
This product contains a CR Coin Cell Lithium Battery
which contains Perchlorate Material—special
handling may apply.
See www.dtsc.ca.gov/hazardouswaste/perchlorate
Before using the remote controller:
• Aim the remote controller directly at the remote
sensor on the unit.
• DO NOT expose the remote sensor to bright light
(direct sunlight or artificial lighting).
OPERATIONS
p
q
r
(track/
Remote sensor
Continued on the next page
5
