Installation instructions, only for experts

4.1. Removing the cover plates

To install the safety shut-off, cover plate 2 and the cover plate on the opposite
side 6 must be removed (see Fig. 1 on page 8). To do so, perform the
following steps:
1. Unscrew the screws 3 and 4 with a screwdriver.
2. Unscrew the screws 1 and 5 with a screwdriver.
3. Remove the cover plate 2.
4. Perform the same steps to remove the cover plate on the opposite side 6.
6
5
Fig. 1 Removing the cover plates
WORLD OF WELLNESS
p. 8/18
1
2
3
4
