Installation, Operation and
Maintenance Manual
Model OF1465, OF1665
OneFlow
Anti-Scale Systems
®
Chemical-Free, Salt-Free Scale Prevention
Read this Manual BEFORE using this equipment.
Failure to read and follow all safety and use infor-
mation can result in death, serious personal injury,
property damage, or damage to the equipment.
Keep this Manual for future reference.
Introduction
The Watts OneFlow
Anti-Scale System provides protection from
®
scale formation on internal and external plumbing surfaces. The
OneFlow
system can be installed at the point of entry to a build-
®
ing to treat both hot and cold water, or it can be located directly
before a water heater, boiler, or other water using device that
requires protection from hard water.
OneFlow
prevents scale by transforming the normal dissolved
®
hardness minerals into undissolved crystal microparticles. These
crystals stay suspended in the water and have a greatly reduced
ability to react and attach to surfaces like dissolved hardness
does. Therefore the problem of internal buildup of scale in pipes,
water heaters and on fixtures and glass is greatly reduced.
OneFlow
is not a water softener – Water treatment chemistry (e.g.
®
antiscalants, sequestrants, etc.. will most likely have to be changed
to be compatible with OneFlow
washing chemistry will likewise require adjustments.
OneFlow
Benefits
®
• C hemical free scale prevention. Cost savings and environmental
benefits.
• V irtually maintenance free. No salt bags or other chemicals to
buy, transport and store.
• N o electricity, no wastewater, completely self-contained.
• I mproves the efficiency of water-using appliances.
• S imple installation – no electrical and drain hookup.
• S afe for landscaping and lawn watering. No need for costly
bypass plumbing.
• C ompatible with all on-site and community wastewater treat-
ment systems.
• N ot subject to water softener restrictions and "bans".
• O neFlow
treated water has no added sodium, is safe to
®
drink and is well suited for use in food and beverage prepa-
ration.
treated water. Laundry and ware-
®
IOM-OF1465_1665
