Large Panel - Lutron Softswitch128 Guide D'installation

Panel Dimensions
(continued)
Large Panel (120/277/347 V only)
Dimensions are in inches (mm).
22.0
(559)
Top View
6.30
23.50
(160)
(597)
2.50 (64)
0.15
(4)
3.34 (85)
45.00
(1143)
63.00 63.50
(1613)
(1600)
Cover
18.50 (470)
Right Side
Left Side
22.75 (578)
Front View
6.1 (155)
Bottom View
6 Installation Guide for Switching Panels
