Contents
1. Presentation .............................................. 14
2. Description ................................................ 15
3. Selftest ....................................................... 15
4. Auto AC/DC voltage polarity detection ..... 16
5. Phase/neutral identification ....................... 17
6. Continuity - Resistance measurement .... 18
7. Phase rotation ........................................... 19
8. General characteristics ............................ 20
9. Conformity to international standards ...... 20
10. Guarantee ............................................... 21
11. To order ................................................... 21
12. Maintenance ............................................ 22
13. Appendix .................................................. 54
1. Presentation
C.A 704 is a multimeter .
Lighting, AC/DC detection and automatic change
of ranges all guarantee improved safety and
more practical operation for the user.
The design and manufacture of this product
according to EN 61010-1 600V CAT III and
EN 61243-3 standards make this product a
professional tool that you may use for diagnostic
operations or when checking for the absence of
voltage.
C.A 704 enables you to measure:
- AC and DC voltages
- resistances
It also includes:
- continuity sound testing
- phase/neutral identification
- inclination of the phase rotation direction
(« 2-wire » method)
- display backlighting
- maintained voltage measurement
- an automatic lighting and extinguishing
device
This instrument provides the following
advantages :
- rugged tool.
- handless easily on 2P + E current sockets
with the C.A 751 adapter (optional).
14
