9.2 Spare Parts list

Model : 74166
NO ERP
1 133050118 Top cover
2 180140092 Top frame
3 180140113 Left side panel
4 180140100 Fan motor bracket
5 103000227 Evaporator
6 112000031 Fan motor
Evaporator heating resistor
7 108480015
support
8 132000015 Fan blade
9 180140093 Pillar
10 133050115 Front panel
11 133020077 Fan grill
12 117020293 Controller
13 136010072 Sealing ring
14 133020096 Controller cover
15 133020097 Controller box
16 180140091 Base tray
17 180140099 Isolation panel
18 180140101 Panel support
19 142000143 Evaporator heating resistor
20 142000072 Compressor heating resistor
21 101000187 Compressor
22 101000187 Compressor damping feet
23 133050116 Right panel
24 106000011 Pressure gauge
25 103000227 Evaporator pipe
26 133250005 Terminal blocks plastic cover
27 136010004 Clip
28 115000004 5-ways terminal block
29 108010065 Terminal board
30 103000227 Distribution piping
31 113190001 Sensor holder
32 113190007 Clip
33 136020018 Rubber block
Evaporator temperature
34 117110004
sensor d5-TH2
35 133050117 Back panel
9 9 9 . . . Exploded Exploded Exploded
Spare parts NO
Diagram Diagram Diagram
ERP
36 117230003 Reactor
37 117110020 Ambient temp. sensor d3-TH1
38 133020010 Ambient temp. sensor clip
39 108030059 Electric box cover
40 117240002 Magnet ring
41 117240003 Magnet ring
42 117100046 PCB
43 108030095 Electric box
44 117020239 Modbus module
45 121000035 4 way valve
46 113030192 4-way valve to exchanger
47 113070042 Exchanger to EEV
48 113020320 Gas return piping
49 120000098 Gas valve
50 119000058 EEV
51 113080074 EEV to distribution piping
52 109000044 Capillary
53 113060123 Tube
54 117110021 Discharge temp. sensor d6-TH3
55 113010229 Discharge pipe
56 112100030 High pressure switch
57 112100046 Low pressure switch
58 113100024 Coupling tube
59 102041058 Titanium heat exchanger
60 117110011 Water outlet temp. sensor d2-TH5
61 108010025 Exchanger temperature sensor clip
62 112100021-1 Water flow switch
63 116000001 Sealing ring
64 133020026 Rubber ring on water connection
65 133020012 Red rubber ring
66 113900082 Water connection sets
67 133020011 Blue rubber ring
68 150000110 Drainage plug
69 117110012 Water inlet temp. sensor d1-TH6
- 101 -
