Additional Clearances - Vent Terminal (RC80i, RC98i)

Local codes supersede these clearances.
•
Avoid termination locations near a dryer vent.
•
Avoid termination locations near commercial cooking exhaust.
•
For air intake position, follow the ANS Z21.10.3, CSA 4.3 requirements on the previous page.
Vent terminal (represents concentric vent terminal or exhaust only vent terminal)
12"
(0.30 m ) to an
inside corner
(1.52 m) between
Rinnai terminals
at different levels
V
28
(0.91 m) to ventilated
or unventilated soffit
36"
or eve vent; or to a
deck or porch
V V
12"
(0.30 m) between
Rinnai terminals at
same level
INSIDE
CORNER
60"
V
Manual - Rinnai Condensing Water Heaters
V
60"
(1.52 m) vertically
between Rinnai terminals
V
(0.61 m) to wall or parapet
24"
V
12"
(0.30 m) between
Rinnai terminals at
V V
same level
