ACCESSORY STORAGE & ASSEMBLY
Your WORKSHOP Wet/Dry Vac is
designed to provide better accessory
storage which is built into the four caster
feet. You may conveniently store your
accessory nozzles, extension wands and
hose at these locations.
Extension Wand
Utility
Nozzle
Caster Foot
w/Storage

Locking Sleeve

The Locking Sleeve is designed to
provide added strength in accessory
connections.
The Locking Sleeve can be used when
connecting:
• Extension wand to extension wand
(shown)
• Hose to extension wand
• Extension wand to nozzle
To install the Locking Sleeve: slip Locking
Sleeve over accessory end, roll sleeve
back to expose accessory end, attach
accessory and unroll sleeve over
attached accessory.
Extension Wand
Locking Sleeve and Extension
Wands Engaged
8
Extension
Wand
Locking Sleeve
Locking Sleeve
Rolled Back
