General installation instructions!
Please observe the following points before attaching the
monitor:
• Locate monitor first of all on a trial basis.
• The assembly location should be even.
• Check before the final assembly whether the necessary
free space is available, also below the selected assembly
place chosen for the attachment of discs and nuts.
• Consider the weight of the monitor. Are reinforcements
(larger washers or plates) necessary?
• Is the installation of the wiring harness and connecting cable to
the monitor possible?
• Pay attention when locating the monitor that this is not
assembled within the radius of an AIRBAG.
Otherwise there is danger of injury when it is activated.
• Check that connecting cable has sufficient length
from the place of assembly to the connection box.
Assembly:
After having checked above mentioned points attach the
mounting plate (see I 2) with the supplied sheet metal screws
(see I 3) to the vehicle sky (see I 1).
Screw then the monitor with the supplied machine screws to the
mounting plate (see I 4)
Carry out a function test before the assembly.
The assembly place must be protected against humidity. An assembly
under the dashboard is recommendable due to the compact design. The
box can be fastened with the supplied sheet-metal screws or
self-adhesive Velcro tape (not included in the scope of delivery).
Please observe the general installation instructions!
The voltage supply should be provided via a switched voltage source
e.g. group 15. The system has also a certain power consumption when
it is switched off (IRreception active), which can discharge the vehicle
battery over a longer period of time.
11:01
Page 20

Installation of the monitor

Installation of the connection box
