Warning!Inadequate cable connections can lead to short-circuits
which cause the following:
• cable fires
• activation of the airbag
• damage to electronic control equipment
• electrical functions (indicator, brake light, horn, ignition, light)
fail through being short-circuited
Please note the following:
With work on the lines of the vehicle the following
terminal designations apply:
30 (input from battery plus direct)
15 (switched plus, behind battery)
31 (return cable from battery, earth)
The securest form of connection is obtained by soldering the cable
ends and then insulating the connection.
For detachable connections, use only insulated cable brackets,
connector plugs, and flat pin bushings. Do not use crimp connections
(line connector) or wire connectors.
Use crimp pliers for connecting the cables with cable lugs, plugs, or flat
pin bushings.
With cable connections to 31 (earth):
Attach the cable with a bracket and tooth-lock washer to an
earthing screw on the vehicle or screw it onto the metalwork of
the vehicle using a bracket, metal screw and tooth-lock washer.
Always ensure a good earthing connection!
Warning! Due to risk of short-circuiting, always disconnect the
negative pole of the battery before starting with work on the
electrical equipment of the vehicle.
In the case of vehicles with a supplementary battery, also
disconnect this negative pole.
