System Reset; Zone Reset; Changing Batteries; Assembly And Connection Evaluation - Airzone FLEXA 3.0 IBPRO6 Guide D'installation

System reset

If you want to return to factory values, press and hold SW1
LEDS to go back to their normal state before starting with the initial configuration process.
ES

Zone reset

If needed, to reset a zone follow the steps shown in the section Advanced Settings, Zone Parameters for
EN
Blueface and Think thermostats and the section Lite thermostat Reset if using Lite thermostats.
FR

Changing batteries

IT
To replace the battery, separate the thermostat from its support and
replace the battery (CR2450).
PT
Important:
We recommend using of top-brand batteries. Using low-quality
batteries may reduce the duration of use
DE
Remember to deposit the old battery into an appropriate recycling point.
Note: Do not forget to remove the security system before taking away the
thermostat from the wall.

ASSEMBLY AND CONNECTION EVALUATION

Check the following aspects:
- The state of the LEDs of the main control board and the rest of control elements. Check the self-diagnose section of
the data sheet of the elements.
- The main control board LEDs of opening dampers light up sequentially.
- If all the thermostats are powered.
Important: In the main control board, check the correct performance of D3, D11 and D19 LEDs and motorized elements.
20
until LED D19 stops blinking. Wait for the
.
Meaning
Main control board
D3
activity
Main control board
D11
power
Association channel:
D19
active
Open dampers
Close dampers
Blinking Green
Solid Red
Solid Red
Solid Green
Solid Red
