Dip-switch setting:
ON
DIP 1
OFF
ON
DIP 2
OFF
ON
DIP 3
OFF
ON
DIP 4
OFF
ON
DIP 5
OFF
DIP 1
Recommended
setting
ON
FEATURES
POWER SUPPLY
CURRENT ABSORPTION
PULSE COUNT
LENS TYPE
MAXIMUM PIR RANGE
RADIO RANGE
ANTIOPENING
TEMPERATURE COMPENSATION
OPERATING TEMPERATURE
HUMIDITY
DIMENSIONS LXHXD
WEIGHT
GRADE OF PROTECTION

FIRST INSTALLATION

• Insert the provided battery in the transmitter and wait about 10 seconds.
• Make sure that the transceiver is in the learning mode in accordance with instructions from the control panel
programming alarm Comelit.
• Make a transmission by pressing and releasing the "tamper" switch; This starts the data transmission of "learning" from
the device to the transceiver control panel.
EXAMPLE OF DETECTION AREA
active power supply
non-active power supply
not used
LED on
LED off
sensor in OR
sensor in AND
single impulse
double impulse
DIP 2 DIP 3 DIP 4
ON OFF OFF
one 3.6 VDC Lithium battery
Stand-by condition 20 µA – alarm condition 1mA
1 or 2 pulses in 2.5s
fresnel
Max 4 m
Max 500 m in open space
internal contact
automatic
-20° C a +50° C
85% (max)
280 x 38 x 30 mm
190 gr
IP54
FRONT
VIEW
35°
120 cm
DIP 5
OFF
LATERAL
VIEW
50 cm
EXAMPLE
