Key
No. Description
1 Pressure gauge
2 Screen filter
3 Air relief valve
4 O-ring
5 Tank lid assembly (includes Key No. 6)
6 Tank lid O-ring with silicone lube
7 Filter module
8 Diverter
9 Safety catch
10 Filter tank
11 Drain cap assembly with washer
• Instruction decal
• Not illustrated.
1
2
3
4
I N
I N
L E L E
T
T

REPAIR PARTS LIST

Qty.
1 15060-0000T
1 WC8-72D
1 25010-0004
1 U9-359
1 25200-0103S
1 25200-0011S
1 25200-0140S
1 25200-0012
1 25200-0007
1 25200-0001S
1 32185-7074
1 32155-4170
10

EXPLODED VIEW

5
6
7
8
NOTE: Align the arrow on the
Diverter (Key No. 8) with the
Inlet Port on the tank.
9
S H
P U
10
11
PRDE40 PRDE55
15060-0000T
WC8-72D
25010-0004
U9-359
25200-0103S
25200-0011S
25200-0160S
25200-0012
25200-0007
25200-0002S
32185-7074
32155-4170
