The thermostat [96] controls the temperature inside the
refrigerator during operation in both propane gas and AC modes.
You can change the refrigerator temperature to the desired
setting by putting the gas control at any position between
"START" and "5". Position "5" is the coldest temperature setting.
The AC mode button (
120 volts AC electric power.
The DC mode button (
12 volts DC electric power. When operating on 12 volts DC
power, the refrigerator cooling system will run continuously at full
cooling power (with no thermostat control).
The propane gas mode button (
using propane gas. The refrigerator has an electronic ignition.
When you press the propane gas mode button, the electronic
ignition begins ignition by sparking at the burner. The sparking
continues until the propane gas has ignited and the thermocouple
senses that a flame is present.
The "OFF" button [30] to interrupts all power sources and turns
the refrigerator off.
The flame indicator light [217] illuminates when a flame is present
at the burner and indicates that the refrigerator is operating on
propane gas.
Ignition - propane gas operation:
NOTE: During warm and humid weather conditions, operate
the refrigerator in either AC mode or DC mode for a
minimum of five minutes before you try to start up the
refrigerator in propane gas mode.
1. Open the valve at the propane gas storage tank.
2. Turn the thermostat to the "START" position.
3. Push the propane gas mode button (
4. Push and hold in the gas safety valve.
- Hold in the gas safety valve until the flame meter illuminates.
- Continue to hold in the gas safety valve for about 15
seconds only.
- Do not hold in the gas safety valve for more than 30
seconds.
!
WARNING:
more than 30 seconds. If there is no flame in
this time, wait at least five minutes before you
try ignition again. If you continue to hold the gas
control in, gas will collect in the burner area. This
could cause a fire or an explosion and result in
dangerous personal injury or death.
Installation and Owner's Guide 4
) [35] starts up the refrigerator using
) [164] starts up the refrigerator using
) [36] starts up the refrigerator
).
Do not hold the gas control in for
- If the flame meter does not illuminate, release the gas safety
valve and push the "OFF" button.
- Wait five minutes and do Steps 3 and 4 again.
5. Turn the thermostat to the desired temperature setting.
Do a test of the gas safety valve:
With an established flame in propane gas mode:
1. Close the manual gas shutoff valve of the refrigerator.
2. After the flame is extinguished, you should hear a sharp "click"
sound within three minutes.
NOTE: The gas safety valve should close with a sharp "click"
sound.
3. Open the manual gas shutoff valve of the refrigerator.
4. Push the propane gas mode button (
5. Do not push in the gas safety valve. The burner flame should
not ignite. This means that the gas safety valve is working
correctly.
Start up - AC mode operation:
- Push the AC mode operation button.
- Turn the thermostat to the "5" position.
- Allow the refrigerator to operate at this setting for 6- 8 hours
before changing to the desired temperature setting.
Start up - DC mode operation:
- Push the DC mode operation button.
The refrigerator receives its DC power from the 12 volt system
of the vehicle; either the vehicle engine battery or an auxiliary
(house) battery. The 12 volt system of the vehicle supplies
DC power not only to the refrigerator but also to any other
DC appliances of the vehicle. When operating on DC, the
refrigerator has a high current draw and can cause a rapid
battery discharge.
DC operation precautions:
This refrigerator is made to operate on DC power while your
vehicle is "in transit" and AC power or propane gas sources are
not available. Operate the refrigerator on DC power only when
the vehicle engine is running.
For the refrigerator to operate correctly on DC power, the battery
must be maintained in a fully charged condition.
).
