4. ASSEMBLE MIDDLE RIBS
Assemble middle ribs as shown in Fig. 3. Securely fasten all of the joints with
#11131 (2-3/4") Bolts and Nuts.
Fig.3
11068
11013
11019
11270
5. ASSEMBLE WIND BRACES
Assemble all of the wind braces as shown in Fig. 4. Securely fasten the joints with the hardware indicated.
Fig.4
11135
11068
800402
11019
11131
11270
11095
Page 5
11068
800403
00690
00648
00690
11068
11013
11019
11270
11093
05_GP-AA-XXXXXXA-022XXX11_H0
