Controls and connections

* & ^ %
CD CHANG E
STAN DBY•O N
ECO POW ER
DISP LAY
( ) ¡ ™ £

On the back

1
SPEAKERS 6 Ω L/R
connect to the supplied speakers
2
VOLTAGE SELECTOR
110V–127V, 220V–240V
(Not on all versions.) Set this selector to the local mains
voltage. Disconnect the mains lead before resetting this
selector.
3
AC MAINS ~
After all other connections have been made, connect
the mains lead to the wall socket.
4
DIGITAL IN
connect to the coaxial output of a digital appliance
10
$ # @ !
OPEN•CLOSE
ON•OFF LEVEL
AUX
MIC /
LEV EL
MIC
≤ ∞ § ≥
0 9 8 7
R
1
• ª º
5
FM ANTENNA
connect the supplied wire antenna here
6
AM ANTENNA
connect the supplied loop antenna here
7
LINE OUT R/L
connect to the analogue audio input of an additional
appliance
8
AUX/CDR IN R/L
connect to the analogue audio output of an additional
appliance
9
SUBWOOFER OUT
connect to the input of a subwoofer
6 5 4
L
LINE
OUT
AUX/
CDR
IN
ANTE NNA
AM ANTE NNA FM
SU BW OO FER
OU T
3
DIGIT AL
IN
AC
MA INS
~
VOL TAG E
SEL ECT OR
110 V-
127 V
220 V-
240 V
NOT FOR ALL
VER SIO NS
