Keypad actions and shortcuts
Switch the locator or transmitter on by pressing the
function as follows:
Locator keys
K EY ● S H OR T P R E S S
Enter the menu
Scroll through locate frequencies
from low to high
When using active frequencies:
Toggles Peak, Peak+, Null, Broad Peak
and Guidance antenna modes.
In Power Mode:
Scrolls through Power Filters
™
discrimination of parallel or strong power
signals
Increase and decrease gain.
and RD8100 automatically sets gain to
mid-point when pressed
Take a Survey Measurement and send
over Bluetooth if paired
Send an iLOC command to a paired
transmitter
Transmitter keys
K EY ● S H OR T P R E S S
Enter the menu
Scroll through locate frequencies
from low to high
Take voltage and impedance measurements
using the currently selected frequency
and Adjusts the output signal
Tip: to scroll through frequencies from high to low, hold
(applies to both locators and transmitters).
key. Once powered up, the keys
● ■ ■ ■ ●
LON G P R E S S
Switch power off
SideStep ™ (see 'iLOC' section)
When using Current Direction :
™
Perform a CD Reset
In Peak+ antenna mode:
Switch between Guidance and Null arrows
for improved
Rapidly increase and decrease gain steps
in 1dB increments
–
Enter the Transmitter power setting menu
for use over iLOC
● ■ ■ ■ ● LON G P R E S S
Switch Power off
–
Take voltage and impedance
measurements at a standardized frequency
Select standby / maximum standard
power
while pressing the button
10

Before you begin

IMPORTANT!
This guide is intended to be a quick reference guide. We recommend you read the
full operation manual before you attempt to operate the RD8100 locator.
First use
The RD8100 locators and transmitters can be powered by D-cell alkaline batteries,
D-cell NiMH batteries, or by an accessory Lithium-Ion (Li-Ion) battery pack.
To fit the D cell batteries in the locator, open the battery compartment and insert two
D-Cell Alkaline or NiMH batteries, taking care to align the positive (+) and negative (-)
terminals as indicated.
To fit the D cell batteries in the transmitter, unlatch the accessory tray. The battery
compartment is located underneath the transmitter body. Use the turnkey to unlatch the
battery compartment. Insert eight D-Cell Alkaline or NiMH batteries, taking care to align
the positive (+) and negative (-) terminals as indicated.
Alternatively, you can power the transmitter from a mains or vehicle power source using a
Radiodetection supplied optional accessory adapter.
Rechargeable battery packs
Lithium-Ion battery packs are available for both locators and transmitters, providing
superior performance over traditional alkaline batteries. To fit these rechargeable packs,
follow the instructions provided with each pack.
Checking your system software version
If you wish to check which version of software is running on your locator, press and
hold the key when switching the locator on. This information may be asked for when
contacting Radiodetection or your local representative for technical support.
Transmitters automatically show their software version on startup.
System setup
It is important that you set up the system according to regional / operational requirements
and your personal preferences before you conduct your first survey. You can set the
system up using the menus as described below.

Setting up your system

The RD8100 locator and transmitter menus allow you to select or change system options.
Once entered, the menu is navigated using the arrow keys. Navigation is consistent on both
the transmitter and the locator. When in the menu, most on-screen icons will temporarily
disappear and the menu options will appear in the bottom left-hand corner of the display.
The right arrow enters a submenu and the left arrow returns to the previous menu.
