Preparing the locator:
1.
Press the
key to enter the menu.
2.
Scroll to the BT menu using the
or
3.
Press the
key to enter the BT menu.
4.
Scroll to the PAIR menu and press the
5.
Scroll to the BT-TX option.
NOTE: You must complete the pairing process within 90 seconds to prevent the
locator's Bluetooth connection from timing out.
Preparing the transmitter:
6.
Press the
key to enter the menu.
7.
Scroll to the BT menu using the
or
8.
Press the
key to enter the BT menu.
9.
Scroll to the PAIR option.
Starting the pairing process:
10. Press the
key on the transmitter followed by the
11. The transmitter and the locator will now attempt to pair.
When pairing is in progress, the transmitter and locator will display a flashing Bluetooth
icon. Pairing can take up to a minute. If the pairing process is successful, the transmitter
will display the
icon and the locator will display a persistent Bluetooth icon for the
duration of the connection.
If pairing fails, ensure that any nearby Bluetooth devices are switched off or invisible then
repeat the process.
Once the locator and transmitter have successfully paired you can use iLOC to change the
transmitter's output frequency and power levels remotely from the locator.
Using iLOC
The locator and transmitter need to
be paired to use iLOC. For optimum
performance:
•
Try to minimize obstructions in line of
sight.
•
If possible, raise the transmitter off the
ground by 30-60cm (1-2ft).
•
Face the rear end of the transmitter
towards the locator.
•
Point the screen of the locator towards
the transmitter.
keys.
key to enter it.
keys.
key on the locator.
24
NOTE: If any iLOC commands fail, move closer to the transmitter and repeat the
process.
Changing frequencies
Once the transmitter and the locator are paired, you can change the transmitter's output
frequency remotely using the locator:
1.
On the locator, select the frequency you want by pressing the
frequency is displayed on screen.
2.
Press the
key to send the new frequency to the transmitter.
3.
The locator will display SEND momentarily and then OK if the transfer is successful.
4.
If the transfer is unsuccessful, the locator will display a bluetooth error code error
code.
If the process fails, you may be out of range or there may be an error in the connection.
Move closer to the transmitter and retry the procedure. If the connection continues to fail,
return to the transmitter and reset the connection.
Adjusting power
iLOC lets you adjust the transmitter's power output remotely; you can also put the
transmitter into standby mode and then wake it remotely.
1.
Transmitter power options are located in the TXOUT menu on the locator.
Press and hold the
key to display the TXOUT menu.
2.
Press the
key to enter the power level menu.
3.
Scroll up or down through the power output options using the
•
STDBY: Transmitter standby mode, the connection is still active but the output
is disabled – use to prolong battery life.
•
LOW: Low power output.
•
MED: Medium power output.
•
HIGH: High power output.
•
BOOST: Temporarily boosts transmitter power output to its maximum level.
4.
Once you have selected the mode you want, press the
5.
Press and hold the
key to select the new setting and exit the menu.
6.
Press the
key once to send the settings to the transmitter.
NOTE: When changing the transmitter frequency using iLOC, the chosen transmitter
power setting will be retained.
key until the
or
keys:
key to confirm.
25
