42U Rack Enclosure RK4236BKB *actual product may vary from photos FR: Guide de l’utilisateur - fr.startech.com DE: Bedienungsanleitung - de.startech.com ES: Guía del usuario - es.startech.com NL: Gebruiksaanwijzing - nl.startech.com PT: Guia do usuário - pt.startech.com IT: Guida per l’uso - it.startech.com For the latest information, technical specifications, and support for this product, please visit www.StarTech.com/RK4236BKB.
Page 2
StarTech.com. Where they occur these references are for illustrative purposes only and do not represent an endorsement of a product or service by StarTech.com, or an endorsement of the product(s) to which this manual applies by the third-party company in question. Regardless of any direct acknowledgement elsewhere in the body of this document, StarTech.com hereby...
Page 3
Warning statements Advertencias de uso Make sure that you assemble this product according to this instructions. Asegúrese de ensamblar este producto según las instrucciones. Do not exceed the weight capacity of this product. Overloading this product might result in injury or Asegúrese de no exceder la capacidad de peso de este producto.
Page 4
Varningsmeddelanden Se till att du monterar produkten i enlighet med instruktionerna. Överskrid inte produktens viktkapacitet. Överbelastning av produkten kan orsaka skada på person eller egendom. Denna produkt har stöd för följande vikter: 907 kg. Produkten är endast avsedd för användning inomhus och ska inte användas utomhus. Detta skåp är extremt tungt.
Table of Contents Warnings ....................i Product diagram ..................1 Package contents ...................2 Unpack the enclosure cabinet .............2 Lock or unlock the front door ..............3 Ground the enclosure cabinet .............3 Remove the side panels ................4 Reattach the side panels ...............4 Access your cables .................4 Reverse the front door ................5 Adjust the depth of the mounting rails ..........6 Adjust the leveling feet .................6...
Product diagram 340 mm 340 mm (13 in.) (13 in.) 1000 mm 1000 mm (39 in.) (39 in.) Bottom 600 mm 1000 mm (24 in.) (39 in.) 1973 mm 1973 mm 2050 mm Mesh area Mesh area Mesh area (78 in.) (78 in.) (81 in.) Left...
3. Remove the enclosure cabinet from the pallet and place it onto a firm surface. 4. Examine the enclosure cabinet for any damage and check for missing parts. If anything is damaged or missing, contact StarTech.com. To view contact information for StarTech.com, visit www.StarTech.com/ContactUs.
Lock or unlock the front door • To lock or unlock the front door of the enclosure cabinet, insert one of the provided door keys in the lock on the door and turn the key clockwise or counterclockwise. Ground the enclosure cabinet Warning! This product must be grounded.
Remove the side panels 1. If the side panels are locked, use the provided side-panel keys to unlock the panels. 2. Pull the two tabs on the side panel towards the center of the panel. 3. Lift the side panel free from the enclosure cabinet. 4.
Reverse the front door To accommodate different rack configurations, you can reverse the front door of the enclosure cabinet so that it opens to the left or right. The front door of the enclosure cabinet is attached with levers that are located at the top and bottom of the front door. 1.
Adjust the depth of the mounting rails The mounting rails come preinstalled in the enclosure cabinet. Both the front and back sets of mounting rails can be adjusted independently in 3/4 inch (20 mm) increments to accommodate different sizes of equipment. Warning! Do not attempt to adjust the mounting rails when equipment is installed in the enclosure cabinet.
Install equipment Warning! When you load equipment into the enclosure cabinet, load the heaviest equipment in the bottom section of the rack first. Continue loading equipment in a descending order of weight, so that the lighter equipment is installed in the upper sections of the enclosure cabinet and the heavier items are on the bottom.
