12U Hinged Wall-Mount Rack
Enclosure
RK1224WALHM
FR: Guide de l'utilisateur - fr.startech.com
DE: Bedienungsanleitung - de.startech.com
ES: Guía del usuario - es.startech.com
NL: Gebruiksaanwijzing - nl.startech.com
PT: Guia do usuário - pt.startech.com
IT: Guida per l'uso - it.startech.com
For the latest information, technical specifications, and support for
this product, please visit www.StarTech.com/RK1224WALHM.
Manual Revision: 04/05/2017
*actual product may vary from photos

Publicité

loading

Sommaire des Matières pour StarTech RK1224WALHM

  • Page 1 12U Hinged Wall-Mount Rack Enclosure RK1224WALHM *actual product may vary from photos FR: Guide de l’utilisateur - fr.startech.com DE: Bedienungsanleitung - de.startech.com ES: Guía del usuario - es.startech.com NL: Gebruiksaanwijzing - nl.startech.com PT: Guia do usuário - pt.startech.com IT: Guida per l’uso - it.startech.com For the latest information, technical specifications, and support for this product, please visit www.StarTech.com/RK1224WALHM.
  • Page 2 StarTech.com. Where they occur these references are for illustrative purposes only and do not represent an endorsement of a product or service by StarTech.com, or an endorsement of the product(s) to which this manual applies by the third-party company in question. Regardless of any direct acknowledgement elsewhere in the body of this document, StarTech.com hereby...
  • Page 3 注意 Warning statements 必ず取扱説明書に従って本製品の組み立てを行って下さい。 Make sure that you assemble this product according to the instructions. Read the entire manual and make sure that you understand the instructions before you start to assemble 最初に取扱説明書を最後まで読み、 本製品の組み立て方をすべて理解してから組み立て作業を and use this product. 始めて下さい。 Wall structures vary, and it is important to make sure that the type of wall structure and mounting 壁面の構造は建物によって異なります。...
  • Page 4 Mensagens de aviso Certifique-se de que monta este produto de acordo com as instruções. Leia todo o manual e certifique-se de que entende as instruções antes de começar a montar e a utilizar este produto. As estruturas de parede variam e é importante certificar-se de que o tipo de estrutura de parede e hardware de montagem que está...
  • Page 5 Table of Contents Warnings ..............................i Introduction ....................1 Product diagram ............................1 Product dimensions ..........................2 Package contents ............................3 Requirements ............................. 3 Ground the enclosure ................4 Lock or unlock the front or rear door ..........5 Remove the side panels ................5 Access your cables .................7 Reverse the front door ................8 Adjust the depth of the mounting rails ..........10...
  • Page 6 Introduction Product diagram Front door Rear door Horizontal mounting rail Vertical mounting rail Cable access cover Cable access opening Side panel Vent Instruction manual...
  • Page 7 Product dimensions Top and bottom panels 270 mm 65 mm 30 mm 650 mm Front door Side panels 650 mm 600 mm 637 mm 637 mm Enclosure Back of enclosure 28.6 mm 600 mm 406.4 mm 637 mm 637 mm 542.6 mm 450 mm Instruction manual...
  • Page 8 • Appropriate tools and mounting hardware for the type of wall you’re using Requirements are subject to change. For the latest requirements, please visit www.StarTech.com/RK1224WALHM. Note: The images in this manual depict RK12WALHM. The only difference between RK12WALHM and this product is the rack height and depth.
  • Page 9 Ground the enclosure Warning! This product must be grounded. Do not use this product without an earth ground connection. 1. Use an M6 screw to attach a grounding wire to the front or rear grounding point on the enclosure. 2. Route the wire under the frame of the enclosure and connect the wire to your facility’s earth ground connection.
  • Page 10 Lock or unlock the front or rear door For additional security, the front and rear door of the enclosure can be locked with the provided door keys. • To lock or unlock the front or rear door of the enclosure, insert one of the provided door keys in the lock on the door and turn the key clockwise or counterclockwise.
  • Page 11 3. Lift the side panel free from the enclosure. (figure 3) 4. Repeat steps 1 to 3 to remove the other side panel. figure 3 To put the side panels back on the enclosure, place one of the side panels in the groove at the bottom of the enclosure.
  • Page 12 Access your cables There are two cable access covers on the enclosure that you can remove to access and manage your cables. 1. To take off a cable access cover, use a Phillips type screwdriver to remove the two screws on both ends of the cable access cover. 2.
  • Page 13 Reverse the front door To accommodate different rack configurations, you can reverse the front door of the enclosure so that it opens to the left or right of the enclosure. The front door of the enclosure is attached to the enclosure with levers that are located at the top and bottom of the front door.
  • Page 14 4. Position the front door so that the top and bottom levers are aligned with the washers located in the hinge area of the enclosure. 5. In the top corner of the front door, pull the lever down and release it into the washer and hole in the enclosure.
  • Page 15 Adjust the depth of the mounting rails The mounting rails come preinstalled in the enclosure but you can adjust the mounting rails to accommodate different sizes of equipment. Both the front and back set of mounting rails can be adjusted independently in 3/4 inch (20 mm) increments. Warning! Do not attempt to adjust the mounting rails when equipment is installed in the enclosure.
  • Page 16 Use the mounting rail tapped holes The mounting rails come preinstalled in the enclosure but you can adjust the mounting rails so that you can use the tapped holes to install your equipment. Warning! Do not attempt to adjust the mounting rails when equipment is installed in the enclosure.
  • Page 17 The wall structure should be capable of supporting at least four times the weight of the mounted equipment. The RK1224WALHM weighs 64 lb. (29 kg) and can hold up to 198 lb. (90 kg) in weight. Warning! If you lack the necessary expertise to attach this product to the wall that you’re using, contact a construction professional to install the enclosure or to provide...
  • Page 18 Install equipment Warning! Do not add equipment to the enclosure until the enclosure is securely attached to the wall. Warning! When you load equipment into this enclosure, load the heaviest equipment in the bottom section of this enclosure first. Continue loading equipment in a descending order of weight, so that the lighter equipment is installed in the upper sections of this enclosure and the heavier items are on the bottom.
  • Page 19 Limitation of liability In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their officers, directors, employees or agents) for any damages (whether direct or indirect, special, punitive, incidental, consequential, or otherwise), loss of profits, loss of business, or any pecuniary loss, arising out of or related to the use of the product exceed the actual price paid for the product.
  • Page 20 StarTech.com is an ISO 9001 Registered manufacturer of connectivity and technology parts. StarTech.com was founded in 1985 and has operations in the United States, Canada, the United Kingdom and Taiwan servicing a worldwide market.
